7.00-20 Steel Truck Wheel Rim - 14mm Bolts

FINISHES WH-7.00-20-14
SIZES Shandong, China
OFFSET RANGE 7.00-20 truck wheel, 14mm steel rim, medium truck wheel, 20 inch steel rim, UWHCO wheel manufacturer, truck steel wheel China
BOLT PATTERNS

7.00-20 Steel Truck Wheel Rim - 14mm Bolts

UWHCO 7.00-20 Steel Truck Wheel Rim manufactured with premium materials and precision engineering. ISO/ATF 16949 certified quality for global markets.

Key Features:

Q235B Steel construction for superior durability
Tube Type design for reliable performance
8 holes / 14mm bolt pattern
PCD: 275 mm
Primer / Silver finish for corrosion resistance
ISO/ATF 16949 certified manufacturing

Applications:

Medium Trucks, Light Dump Trucks

Technical Specifications

Parameter	Value
Rim Size	7.00-20
Type	Tube Type
Bolt Holes	8 holes / 14mm
PCD	275 mm
Material	Q235B Steel
Finish	Primer / Silver
Weight	~35 kg
Application	Medium Trucks, Light Dump Trucks
Certification	ISO/ATF 16949

Packaging

Standard export packaging with individual protective wrapping. Palletized for safe transportation. Custom packaging available for OEM orders.
